DETERMINE LIMITS
PC-6
ON BOARD CHARGING UNIT
With 110-220 Volt system voltage,
recharge within 4-6 hours
80 KM RANGE
With full charge
80 km range
0 EMISSION
100% electrical,
environmentally friendly
AC MOTOR
Clean environment,
high performance
SOLID & AESTHETIC
With the dynamic and elegant design,
all eyes are on you
REGENERATIVE BRAKE SYSTEM
Increase of efficiency in
energy consumption
PC-6 | Technical Specifications
Power
Steering
& Suspension System
Brake System
Body & Chassis
Performance
General
Dimensions
Warranty
PC-6 Technical Specifications
| POWER ELECTRIC-48 V (AC) |
||||||
| Motor Power |
AC 6 kW (8.20 hp) Rated 12.46 kW (16.95 hp) Peak 10 kW (13.60 hp) Rated 22.43 kW (30.50 hp) Peak |
|||||
|---|---|---|---|---|---|---|
| Battery |
Lead-Acid Battery Package 8x6V (11.52 kWh) Lithium Battery Package (10.8 kWh) |
|||||
| Charge Unit |
Lead-Acid Battery Package DELTA-Q QuiQ 1000 Onboard Charge Unit 110-220 VAC@8 1A/48V Lithium Battery Package OVARTECH 3.3 kW Onboard Charge Unit 85-265 VAC@16A 40A/48V |
|||||
| Motor Control Unit |
AC CURTIS (450 A-600 A) |
|||||
| STEERING & SUSPENSION SYSTEM | |||||
| Steering | Self-compensating double reduction helical rack-and-pinion | ||||
|---|---|---|---|---|---|
| Suspension Front |
Fully independent McPherson style strut suspension | ||||
| Suspension Rear |
Semi independent leaf springs w/dual hydraulic shocks | ||||
| BRAKE SYSTEM | |||||
| Service Brake |
Self adjusting mechanical, rear wheel drum brakes and regenerative brake Option: 4-wheel hydraulic drum brake system |
||||
|---|---|---|---|---|---|
| Parking Brake |
Foot actuated multi-lock parking brake Option: Elektromagnetic parking brake |
||||
| BODY & CHASSIS | |||||
| Body |
Naturally colored Thermoplastic ABS White |
||||
|---|---|---|---|---|---|
| Chassis |
Automotive style steel frame with high corrosion resistance Sanding /E-coating/ Static Wet Paint |
||||
| PERFORMANCE | |||||
| Max. Forward Speed |
15 mph - 22 mph (24 kph - 35 kph) * |
||||
|---|---|---|---|---|---|
| Max. Reverse Speed | 5 mph (8 kph) | ||||
| Range |
Lead-Acid Battery Package 80 km ** Lithium Battery Package 80 km ** |
||||
| Max. Gradeability | 25% | ||||
| Charge Time |
Lead-Acid Battery Package 80% - 7 hrs 100% - 9 hrs Lithium Battery Package 80% - 4 hrs 100% - 6 hrs |
||||
| Turning Radius | 18.3 ft (5.6 m) | ||||
|
* Adjustable ** EU: 134/2014 |
|||||
| GENERAL | |||||
| Curb Weight |
Lead-Acid Battery Package 746 kg * Lithium Battery Package 611 kg * |
||||
|---|---|---|---|---|---|
| Passenger Capacity |
1+5 Passenger 1+7 Passenger |
||||
| Load Capacity | 1763 lb (800 kg) | ||||
| Tow Capacity | 3306 lb (1500 kg) | ||||
| Tyre Dimensions |
20.5 x 8-10 (6 ply) |
||||
|
* Standart Vehicle w/ batteries |
|||||
| DIMENSIONS Standart Vehicle w/o Options |
|||||
| Length | 159.4 in (4050 mm) | ||||
|---|---|---|---|---|---|
| Width | 48.2 in (1225 mm) | ||||
| Height |
78.7 in (2000 mm) * 48 in (1220 mm) ** |
||||
| Wheelbase | 130.7 in (3320 mm) | ||||
| Ground Clearance | 5.6 in (143 mm) | ||||
|
* w/ Suntop ** w/o Suntop |
|||||
| WARRANTY | |||||
| Warranty |
2 years full warranty (Less wearable items) 5 years limited warranty (Motor and motor control unit) |
||||
|---|---|---|---|---|---|
