YOUR WAY
PC-2 SL
YOUR WAY
PC-2 SL
YOUR WAY
PC-2 SL
ON BOARD CHARGING UNIT
With 110-220 Volt system voltage,
recharge within 7-9 hours
86 KM RANGE
With full charge
86 km range
0 EMISSION
%100 electrical,
environmentally friendly
AC MOTOR
Clean environment,
high performance
SOLID & AESTHETIC
With the dynamic and elegant design,
all eyes are on you
REGENERATIVE BRAKING SYSTEM
Increase of efficiency in
energy consumption
PC-2 SL| Technical Specifications
Vehicle Category & EU Type Approval Number: L6e-A e13*168/2013*00589*00
Power
Steering
& Suspension System
Braking System
Body & Chassis
Performance
General
Dimensions
Warranty
PC-2 SL Technical Specifications
| POWER ELECTRIC-48 V (AC) |
||||||
| Motor Power |
AC 4 kW (5.44 hp) Rated 9.60 kW (13 hp) Peak |
|||||
|---|---|---|---|---|---|---|
| Battery |
8X6V TROJAN T-125 (11,52 kWh) |
|||||
| Charge Unit |
DELTA-Q QuiQ 1000 Onboard Charge Unit w/ auxillary charge indicator 110-220 VAC@18 1A/48V |
|||||
| Motor Control Unit |
AC CURTIS (350 A) |
|||||
| STEERING & SUSPENSION SYSTEM | |||||
| Steering | Self-compensating double reduction helical rack-and-pinion | ||||
|---|---|---|---|---|---|
| Suspension Front |
Fully independent McPherson style strut suspension | ||||
| Suspension Rear |
Semi independent, swing arm with coil springs over hydraulic shock absorbers | ||||
| BRAKE SYSTEM | |||||
| Service Brake | 4-wheel hydraulic drum brake system | ||||
|---|---|---|---|---|---|
| Parking Brake | Elektromagnetic parking brake | ||||
| BODY | |||||
| Body |
Naturally colored Thermoplastic ABS White, Midnight Blue, Red, Black |
||||
|---|---|---|---|---|---|
| Chassis |
Automotive style steel frame with high corrosion resistance Sanding /E-coating/ Static Wet Paint |
||||
| PERFORMANCE | |||||
| Max. Forward Speed | 40 km/h (25 mph) * | ||||
|---|---|---|---|---|---|
| Range | 86 km (53 mi) ** | ||||
| Max. Gradeability | 20% | ||||
| Charge Time |
80% - 7 hrs 100% - 9 hrs |
||||
| Turning Radius | 3m (9.80 ft) | ||||
|
* Adjustable ** EU: 134/2014 |
|||||
| GENERAL | |||||
| Curb Weight | 1404,3 lb (637 kg) * | ||||
|---|---|---|---|---|---|
| Passenger Capacity | 1+1 Passenger | ||||
| Load Capacity | 643,7 lb (292 kg) | ||||
| Towing Capacity | 1102 lb (500 kg) | ||||
| Tyre Dimensions |
20.5 x 8-10 (6 PLY) |
||||
| * Standart Vehicle w/ batteries | |||||
| DIMENSIONS Standart Vehicle w/o Options |
|||||
| Length | 96,8 in (2460 mm) | ||||
|---|---|---|---|---|---|
| Width | 48,1 in (1222 mm) | ||||
| Height | 77,3 in (1965 mm) | ||||
| Wheelbase | 64,8 in (1646 mm) | ||||
| Ground Clearance | 5,5 in (140 mm) | ||||
| WARRANTY | |||||
| Warranty |
2 years full warranty (Less wearable items) 5 years limited warranty (Motor and motor control unit) |
||||
|---|---|---|---|---|---|
